Interior expansion system CombiLine N
N/PE busbar system and terminal blocks, M(B)N...74+75

• For 2-pole busbars, see below
• With busbar bracket type ZX518
• With end cover type ZX519
• Additionally braced in the middle from 3-field width
• DIN rail that is variably adjustable in depth via the deep
angle piece ZW59P2
• Usable depth from 90 mm to 145 mm
MN374 MN375 • Usable width for terminal blocks: 1-field width 188 mm,
2-field width 438 mm, 3-field width 688 mm
• Rated current (I ) max. 440 A
n
• Important: note the possibility to combine modules
with the TwinLine cabinet row mountings
• The mounting frame must be ordered separately y

With one additional DIN rail for terminal blocks
Kit Mounted
Height Width From cabinet depth not installed and installed in the cabinet
RE mm FB mm PLE EDF* WR* 2 mm Type Order code Type Order code
1
2 300 1 250 24   200 MBN174 2CPX041746R9999 MN174 2CPX041281R9999
2 500 48   200 MBN274 2CPX041748R9999 MN274 2CPX041282R9999
3 750 72   200 MBN374 2CPX041750R9999 MN374 2CPX041283R9999
With two additional DIN rails for terminal blocks
3 450 1 250 36   200 MBN175 2CPX041752R9999 MN175 2CPX041284R9999
2 500 72   200 MBN275 2CPX041754R9999 MN275 2CPX041285R9999
3 750 108   200 MBN375 2CPX041756R9999 MN375 2CPX041286R9999
* 1 Expansion on EDF mounting frame | * 2 Expansion on WR mounting frame

• Busbars for individual cabinet installation
• It is possible to combine different module widths
within the cabinet with continuous busbars
• 2 copper rails are required per module
ZX1015

Copper Kit Mounted
rail I n Width not installed and installed in the cabinet
mm A FB mm Unit Type Order code Type Order code
12 x 5 250 1 246 1 ZX1001 2CPX041870R9999 ZXM1001 2CPX041480R9999
2 496 1 ZX1002 2CPX041871R9999 ZXM1002 2CPX041481R9999
3 746 1 ZX1003 2CPX041872R9999 ZXM1003 2CPX041482R9999
4 996 1 ZX1004 2CPX041873R9999 ZXM1004 2CPX041483R9999
5 1246 1 ZX1005 2CPX041874R9999 ZXM1005 2CPX041484R9999
6 1496 1 ZX1006 2CPX042800R9999 ZXM1006 2CPX042822R9999
20 x 5 320 1 246 1 ZX1013 2CPX041882R9999 ZXM1013 2CPX041492R9999
2 496 1 ZX1014 2CPX041883R9999 ZXM1014 2CPX041493R9999
3 746 1 ZX1015 2CPX041884R9999 ZXM1015 2CPX041494R9999
4 996 1 ZX1016 2CPX041885R9999 ZXM1016 2CPX041495R9999
5 1246 1 ZX1017 2CPX041886R9999 ZXM1017 2CPX041496R9999
18
6 1496 1 ZX1018 2CPX042801R9999 ZXM1018 2CPX042823R9999
30 x 5 440 1 246 1 ZX1019 2CPX041888R9999 ZXM1019 2CPX041498R9999
2 496 1 ZX1020 2CPX041889R9999 ZXM1020 2CPX041499R9999
3 746 1 ZX1021 2CPX041890R9999 ZXM1021 2CPX041500R9999
4 996 1 ZX1022 2CPX041891R9999 ZXM1022 2CPX041501R9999
5 1246 1 ZX1023 2CPX041892R9999 ZXM1023 2CPX041502R9999
6 1496 1 ZX1024 2CPX042802R9999 ZXM1024 2CPX042824R9999
