Interior expansion system CombiLine N
Power switch Tmax unpopulated, M(B)A...T

• Unpopulated for make ABB, fix-mounted installation,
Tmax XT2, 4-pole + 4-pole + RC Sel, 120 mm
Tmax XT4, 4-pole + 4-pole + RC Sel, 140 mm
• Covers with cutout
• With mounting cross beam, including slide nuts M4
• The mounting frame must be ordered separately
• Not suitable for fire protection housing

MBA195T

From
cabinet Kit Mounted
Height Width I n Equipment depth not installed and installed in the cabinet
RE mm FB mm A Type Polarity PLE EDF* 1 WR* 2 mm Type Order code Type Order code
3 450 1 250 160 XT2 4-pole RC Sel 36   200 MBA195T 2CPX042907R9999 - -
3 450 1 250 250 XT4 4-pole RC Sel 36   200 MBA197T 2CPX042909R9999 - -

• Unpopulated for make ABB, fix-mounted installation,
Tmax T4, 3-/4-pole, 105 mm/140 mm
Tmax T5, 3/4-pole, 139.5 mm/186 mm
• Covers with cutout
• Mounting cross beam, including mounting holes with
thread
• The mounting frame must be ordered separately
• Not suitable for fire protection housing
MA292T

3 450 1 250 320 T4 3-/4-pole 36   215 MBA192T 2CPX041646R9999 MA192T 2CPX041121R9999
1 250 400 T5 3-poles 36   215 MBA192T 2CPX041646R9999 MA192T 2CPX041121R9999
2 500 630 T5 3-/4-pole 72   215 MBA292T 2CPX041647R9999 MA292T 2CPX041122R9999
* Expansion on EDF mounting frame | * Expansion on WR mounting frame
