Interior expansion system CombiLine N
Measuring devices/switch cabinet lighting, M(B)U...

• Unpopulated for 4 measuring devices with installation
size 96 x 96 mm
• Arrangement of horizontal measuring devices
• Covers with cutout
• Mounting on mounting cross beam
• The mounting frame must be ordered separately
MU257

Measurement From Kit Mounted
Height Width devices cabinet depth not installed and installed in the cabinet
RE mm FB mm Unit PLE EDF* 1 WR* 2 mm Type Order code Type Order code
1 150 2 500 4 24   225 MBU257 2CPX041809R9999 MU257 2CPX041390R9999
3 750 4 36   225 MBU357 2CPX041810R9999 MU357 2CPX041391R9999
* 1 Expansion on EDF mounting frame | * 2 Expansion on WR mounting frame

• Unpopulated for 1 or 4 measuring devices with
installation size 96 x 96 mm
• At a height of 450 mm with additional DIN rail for rail-
mounted devices 12 PLE
• Covers with cutout
• Mounting on mounting cross beam
• The mounting frame must be ordered separately

MU158 MU156

1 150 1 250 1 12   225 MBU156 2CPX042043R9999 MU156 2CPX042042R9999
2 300 1 250 4 24   225 MBU157 2CPX041811R9999 MU157 2CPX041392R9999
3 450 1 250 4 36   225 MBU158 2CPX041812R9999 MU158 2CPX041393R9999
* 1 Expansion on EDF mounting frame | * 2 Expansion on WR mounting frame
